APC Smart-UPS SRT 3000VA RM Network Card – UPS – 2700 W – 3000 VA – with

Tech Specs
Specifications are provided by the manufacturer.
Header
Manufacturer : APC
Brand : APC
Product Line : APC Smart-UPS SRT
Model : 3000VA RM Network Card
Bundled with : APC UPS Network Management Card AP9631
Packaged Quantity : 1
General
Subcategory : UPS
Product Type : UPS
Networking
Remote Management Interface : USB
Expansion Slots
Expansion Slots : 1 (total) / 0 (free) x SmartSlot
Interface Provided
Interfaces : 1 x EPO (emergency power off), 1 x serial – RJ-45, 1 x management (Fast Ethernet) – RJ-45, 1 x management (USB) – 4 pin USB Type A
Cable Details
Cables Included : Power cable 2.44 m, USB cable – external
Software
Type : Drivers & Utilities
Power Device
Form Factor : Rack-mountable
UPS Technology : On-line
Voltage Provided : AC 120 volt
Frequency Provided : 50/60 hertz
UPS Output Waveform : Sinewave
Power Provided : 2700 watt
Power Capacity (VA) : 3000 volt ampere per kilogram
Voltage Required : AC 120 volt
Frequency Required : 40 – 70 hertz
Input Connector Type : Power NEMA L5-30P
Input Connector Qty : 1
Output Connector Type : Power NEMA L5-30R, 8 x power NEMA 5-20R
Output Connector Qty : 9
Surge Suppression : Yes
Surge Energy Rating : 340 joules
Power Device Features : Audible alarm, LCD display, Emergency power off, Internal bypass
Power Output Connectors Details
Power Output Connectors Details : 8 x power NEMA 5-20R, 1 x power NEMA L5-30R
Battery
Run Time (Up To) : 3 minute (time unit)
Load Type : At full load
Recharge Time : 3 Hours
Lead Acid Battery Features : Leak-proof, Sealed, Maintenance free
Run Time Details
Run Time (Up To) : 10 min at half load, 3 min at full load
UPS
Battery Technology : Lead acid
Miscellaneous
Color : Black
Color Category : Black
Included Accessories : Rack mounting rails
Rack Mounting Kit : Included
Height (Rack Units) : 2
Compliant Standards : CSA C22.2 No. 107.3, RoHS, FCC Part 15 A, UL 1778, IP20, OSHPD, REACH
Environmental Standards
ENERGY STAR : Yes
Dimensions & Weight
Width : 43.2 centimetre
Depth : 63.5 centimetre
Height : 8.5 centimetre
Weight : 31.3 keg
Dimensions & Weight (Shipping)
Shipping Width : 59.9 centimetre
Shipping Depth : 87.1 centimetre
Shipping Height : 24.6 centimetre
Shipping Weight : 39.92 keg
Service & Support
Type : 3-year warranty
Service & Support Details
Service & Support : Limited warranty – 3 years, Limited warranty – batteries – 2 years
Environmental Parameters
Min Operating Temperature : 0 degree Celsius
Max Operating Temperature : 40 degree Celsius
Humidity Range Operating : 0 – 95% (non-condensing)
Sound Emission : 55 dBA
